Perforated plates

– Fire-technical class  – K2-10 B-s1,d0
– Different surface layers
– Standard dimensions or tailor made
– Complete mounting system

Core Material:

– Type: Wooden plaster, shavings, fiber, MDF, x-veneer and furniture board.
– Thickness: 3-35 mm
– Standard lengths: 2440/3050 mm
– Standard width: 1220/1250 mm

Spesialformat leveres på forespørsel.

Veneer

Ash, bamboo, birch, beech, oak, pine, cherry, maple, pear, walnut and wenge.
We can provide more types on request.

Surface treatment

– Untreated
– Polished
– Stained
– Painted
– Fire treated
– UV-laquered (with or without color pigment, max. 5% color addition)

Edge Designs

– Straigth cut
– Rounded
– Chamfered
– Noted
– Edge veneered

Tykkelsen på kantfinér ligger mellom 0,5-1,5 mm.

Perforation

Standard hole diameter: Ø 4 – 5 – 6 – 8 – 10 mm.
Standard c/c distance hole: 20 or 40 mm.

Mounting

montering av himling illustrasjon

Ceiling Assembly

1. A-edge
2. C-edge
3. D-edge
4. E-edge
5. Visible skrews
6. TRY 16193 (dense fugue)
7. TRY 16193 (1,5 mm/4,0 mm fugue)
8. TRY 16194 (10 mm fugue)

montering av vegg illustrasjon

Wall Assembly

1. Visible screws
2. TRY 16193 (dense fugue)
3. TRY 16193/5103 (1,5 mm/4,0 mm fugue)
4. TRY 16194 (10 mm fugue)

montering av vegg illustrasjon

Which plates fits your needs?

Feel free to visit our exhibitions and get help from our experienced advisers to choose your unique solution.
